Hand Pumps
Barrel pumps
Application
Suitable for standard 200-liter barrel.
Material
-
Cast: iron, PVC (for seawater)
Operation
-
Hand level or rotating actuator
Diaphragm pump
-
suction and discharge pump casing cast iron, diaphragm and ball valve made of rubber
Connection |
1 ¼'' |
1 ½'' |
Capacity ca. |
40 l/min |
50 l/min |
Delivery head ca. |
15 m |
15 m |
Pressure and test-pump
-
up to 50 bar pressure, with single piston, pump-casing made of special casting, valves made of bronze, with shut-off valve, drain valve, galvanized water reservoir and pressure gauge
-
Piston Ø: 30 mm
-
Piston stroke: 40 mm
-
Operation pressure: 50 bar
-
Reservoir dimension: 430 x 310 x 330 mm
-
Weight: 14 kg
(With single piston available up to 100 bar, with double piston up to 1000 bar)
